ELEVATOR BANK

                                   SELF      LUXURY/
                                CHECK-IN  TECH SERVE

7TH AVENUE      ENTRY

            Floor Plan - Lobby            MAKERBOT
                                              WALL

            LIGHT THERAPY/INTERACTIVE     SHOWER/BATH
                     MEDIA LED PANEL         SELF DRY

                                                       BUILT IN
                                                       CLOSET/
                                                       STORAGE

              ENTRY

Queen Bedroom Floor Plan - 215 SQ FT
